SGS 100 Litre Direct Drive Air Compressor & Spray Gun Kit - 13.8CFM 3.0HP 100L
| Air Displacement (CFM) | 13.8 |
| Brand | SGS |
| Capacity | 100 |
| CFM Range | 10 to 15 CFM |
| Colour | Black |
| Compressor Type | Portable |
| Corded | True |
| Corded/Cordless | Corded |
| Drive Type | Direct |
| EAN | 5055462719002 |
| Gross Weight (kg) | 101.00 |
| Horse Power (HP) | 3.0 |
| Lubrication Type | Oil-Lubricated |
| Material | Steel |
| Max Flow (LPM) | 414.0 |
| Max Pressure Output (Bar) | 8.0 |
| Net Weight (kg) | 90.90 |
| No Load Speed (RPM) | 2800.0 |
| Operating Pressure (psi) | 116 PSI |
| Power | 2.2 |
| Power Phase | Single Phase |
| Power Source | Electric |
| Product Height (mm) | 785 |
| Product Length (mm) | 1059 |
| Product Width (mm) | 355 |
| Sound Level (db) | 96.0 |
| Tank Size | 100 |
| Voltage (V) | 230 |
| Warranty | 2 Year Warranty |
The SGS 100 Litre Direct Drive Air Compressor & Spray Gun Kit is a powerful, workshop‑ready solution designed for professional users and serious DIY enthusiasts who need strong airflow, fast tank recovery, and reliable performance for spraying, finishing, and general pneumatic work. With a large 100‑litre air receiver, a robust 3 HP motor, and a high‑quality spray gun included, this kit delivers the consistent air supply required for smooth, controlled paint application and a wide range of air tools.
Producing 13.8 CFM air displacement, the compressor rapidly pressurises the tank to minimise downtime and keep your workflow moving. Twin regulated air outlets allow two tools or air lines to run simultaneously, while Euro quick‑release connectors ensure fast, secure tool changes. The included spray gun connects directly via the ¼" BSP Euro quick‑release outlet, ensuring full compatibility and efficient operation.
Safety and control are built in, with a pressure regulator, dual gauges, and CE/GS certification that meets strict European standards. The compressor may contain minimal oil residue from factory testing, but must be filled with oil before first use to ensure smooth operation. A standard 13A UK plug makes it ready to connect to mains power.
Features & Benefits
High‑capacity 100L air receiver for extended spraying and tool runtime
13.8 CFM air displacement for demanding workshop applications
3 HP direct‑drive motor for fast tank recovery and consistent airflow
Twin regulated air outlets for operating two tools simultaneously
Spray gun included — ideal for paint, coatings, primers, and finishing work
Euro quick‑release connectors for fast, secure tool attachment
Safety valve, pressure regulator & dual gauges for precise control
Compatible with all standard 1/4" BSP air tools
CE marked & GS certified for European safety compliance
Standard 13A UK plug for easy connection
Technical Specifications
Air receiver capacity: 100 Litres
Air displacement: 13.8 CFM
Motor power: 3 HP
Maximum pressure: 115 PSI
Input voltage: 230 V (13A plug)
Pump type: Oil‑lubricated direct drive
Air outlets: 2 × Quick Release Female BSP 1/4" Euro‑style valves
Included tool: HVLP spray gun
Use category: Professional & serious DIY
Important Notes
Compressor may contain minimal oil residue from testing — fill with oil before first use
Suitable for professional and serious DIY use; not recommended for continuous commercial duty
EU safety regulation update: Safety valve rings removed; drain tank via the designated bottom valve
