£40.80

Description

Specification

Product Manual

Product Reviews

Q&A

Introducing the NEW Air Compressor from SGS - with 24 Litre receiver tank is ideal for DIY and trade applications such as spray-painting, tyre inflation, nailing and stapling. The 8 bar maximum working pressure, offers a fantastic combination of performance, safety and value for money. The powerful engine ensures a short wait for the tank to pressurise - keeping you working. Fitted with safety valve and pressure regulator with gauges for controlled air pressure.


motor

 The powerful 1.5 HP motor is capable of delivering up to 5.5 CFM.

tank size

The 24-litre tank is ideal for spraying, nailing, stapling, sanding, drilling and cutting.

12

Twin gauges allow you to monitor tank pressure and tool working pressure.


Fitted with euro quick release connectors. The compressor is shipped with oil but may require additional oil before first use. This compressor is fitted with a standard 13A UK plug.


Please note this compressor is for semi-pro and not commercial use. We would not recommend this compressor for use with most impact wrenches due to the tank size. We would recommend a 50L or greater tank size for use with impact wrenches.


Specifications:


Engine Size: 1.5 HP
Power: 0.75kW kW
Voltage: 230 V @ 50 Hz
Rated Speed: 2850 rpm
Air Displacement: 5.5 CFM
Sound Level: 97dB
Current: 4A/4.5A
Motor poles: 2P
Discharge Pressure: 115 PSI / 8 bar
Tank Capacity: 24 litres
Air Outlet: 1/4" BSP to Euro Coupler. The fitting can be swapped for PCL fittings, please check Fitting & Couplers section.
Dimensions: 58 x 25.5 x 58 cm

Covered by a 2 year extended warranty.

SGS are a British company with full spares, warranty and service centre based in our East Midlands HQ. Our air compressors are hand built by our expert engineers to the highest standard of quality and are European CE marked and German GS certified for product safety

Due to a change in EU legislation the safety valve rings have been removed by ALL manufacturers of air compressors. This is due to the ring being incorrectly used to vent the compressor, causing undue wear which should not be present on a safety device. The air should drained from the tank via the valve on the belly of the tank. This location is used so that the water is drained at the same time.
Part Number SC24L
Display Weight 23 Kg
Warranty 2 Year Warranty
Brand SGS
Lubrication Type Oil-Lubricated
Tank Size 24 Litres
Air Displacement (CFM) 5.5 CFM
Portable or Stationary Portable
Sound Level 97 dB
Power 1 kW
Engine HP 1.5 HP
Engine RPM 2850 RPM
Power Source Electric
Voltage 230V
Air Outlet Euro Quick Release
Discharge Pressure 116 PSI / 8 bar
CFM Range 5 to 10 CFM
Start System Direct Online
Colour Black

Leave a Review

Reviews

  • Delivery
    Quality
    Price
    Review by graham bell
    (Posted on 18/06/2021)
    Prompt efficient service
    Received within 2 days and was kept informed of progress. Always excellent.
  • Price
    Delivery
    Quality
    Review by Ian McIlroy
    (Posted on 02/09/2019)
    24L Air Compressor
    I recently purchased a 24L Air Compressor from SGS Engineering, which I received quickly and without any problems. I had a query about the air breathing from the oil filler bung, which I worked with the SGS customer service department to come to an understanding about whether it was a problem or not, which it wasn't. The compressor is a good specification for the price when compared to comparable compressors and appears well built. From my experience of the company and this air compressor so far, I can recommend both the company and the compressor.
  • Price
    Delivery
    Quality
    Review by Lane electrical
    (Posted on 21/08/2019)
    Good service, quality goods, very pleased

Write a review

Please select your rating from below

1 1 star
2 2 star
3 3 star
4 4 star
5 5 star
Price
Delivery
Quality

SGS 24 Litre Direct Drive Air Compressor - 5.5 CFM, 1.5 HP

Product Code: SC24L

£103.19

£85.99 ex VAT

£143.99

save £40.80

  • Coming soon

or click here to contact us for an alternative

* Required Fields

Product Description

Introducing the NEW Air Compressor from SGS - with 24 Litre receiver tank is ideal for DIY and trade applications such as spray-painting, tyre inflation, nailing and stapling. The 8 bar maximum working pressure, offers a fantastic combination of performance, safety and value for money. The powerful engine ensures a short wait for the tank to pressurise - keeping you working. Fitted with safety valve and pressure regulator with gauges for controlled air pressure.


motor

 The powerful 1.5 HP motor is capable of delivering up to 5.5 CFM.

tank size

The 24-litre tank is ideal for spraying, nailing, stapling, sanding, drilling and cutting.

12

Twin gauges allow you to monitor tank pressure and tool working pressure.


Fitted with euro quick release connectors. The compressor is shipped with oil but may require additional oil before first use. This compressor is fitted with a standard 13A UK plug.


Please note this compressor is for semi-pro and not commercial use. We would not recommend this compressor for use with most impact wrenches due to the tank size. We would recommend a 50L or greater tank size for use with impact wrenches.


Specifications:


Engine Size: 1.5 HP
Power: 0.75kW kW
Voltage: 230 V @ 50 Hz
Rated Speed: 2850 rpm
Air Displacement: 5.5 CFM
Sound Level: 97dB
Current: 4A/4.5A
Motor poles: 2P
Discharge Pressure: 115 PSI / 8 bar
Tank Capacity: 24 litres
Air Outlet: 1/4" BSP to Euro Coupler. The fitting can be swapped for PCL fittings, please check Fitting & Couplers section.
Dimensions: 58 x 25.5 x 58 cm

Covered by a 2 year extended warranty.

SGS are a British company with full spares, warranty and service centre based in our East Midlands HQ. Our air compressors are hand built by our expert engineers to the highest standard of quality and are European CE marked and German GS certified for product safety

Due to a change in EU legislation the safety valve rings have been removed by ALL manufacturers of air compressors. This is due to the ring being incorrectly used to vent the compressor, causing undue wear which should not be present on a safety device. The air should drained from the tank via the valve on the belly of the tank. This location is used so that the water is drained at the same time.

Technical Specification

Part Number SC24L
Display Weight 23 Kg
Warranty 2 Year Warranty
Brand SGS
Lubrication Type Oil-Lubricated
Tank Size 24 Litres
Air Displacement (CFM) 5.5 CFM
Portable or Stationary Portable
Sound Level 97 dB
Power 1 kW
Engine HP 1.5 HP
Engine RPM 2850 RPM
Power Source Electric
Voltage 230V
Air Outlet Euro Quick Release
Discharge Pressure 116 PSI / 8 bar
CFM Range 5 to 10 CFM
Start System Direct Online
Colour Black
